Ultra-Thin Titanium Foil

BYC Ti's Ultra-Thin Titanium Foil redefines the limits of metal performance in micro-engineering and advanced manufacturing. Engineered from high-purity titanium (≥99.6%), our foils are available in ultra-thin gauges ranging from 0.01 mm to 0.1 mm, with custom tolerances to meet the strictest technical specifications.

Whether you're working in aerospace, medical devices, electronics, or energy systems, our titanium foil delivers an exceptional combination of light weight, corrosion resistance, and mechanical integrity at microscopic scales.

Ultra Thin Titanium Foil Key Features

Feature	Description
Thickness	0.01 mm – 0.10 mm (custom specs available)
Width	Up to 600 mm (standard); custom widths upon request
Grade Options	ASTM Grade 1, Grade 2, and other grades available
Purity	≥ 99.6% Titanium (CP Ti)
Surface Finish	Bright rolled, matte, or chemically cleaned
Tolerance Control	±0.002 mm standard; tighter tolerances available
Packaging	Cleanroom-grade rolls or flat sheets, vacuum-sealed for purity protection

Why Choose Ultra-Thin Titanium Foil?

High Strength-to-Weight Ratio

Even at sub-millimeter thicknesses, our titanium foils offer superior tensile strength and structural performance compared to aluminum or stainless steel alternatives.

Corrosion & Heat Resistance

Ideal for harsh chemical and thermal environments — from high-vacuum chambers to marine electronics.

Exceptional Workability

Easily formable, weldable, and etchable, BYC Ti foil is suitable for stamping, photo-etching, micro-machining, and thermal bonding.

Certified Quality

Manufactured under ISO 9001-certified processes and compliant with ASTM B265 standards. Full traceability and mill test certifications provided with every order.

Ultra Thin Titanium Foil Applications

Industry	Use Cases
Aerospace	Lightweight shielding, micro-tubes, insulation layers
Medical Devices	Implantable electronics, diagnostic sensors, surgical components
Consumer Electronics	EMI shielding, flexible circuits, battery packs
Energy & Batteries	Hydrogen fuel cell membranes, thin-film solar panels
Scientific Research	Ultra-clean sample carriers, vacuum-compatible spacers, microscopy grids

Ultra Thin Titanium Foil Technical Specifications (Example: Grade 2 Foil)

Property	Value (Typical)
Thickness	0.025 mm
Yield Strength	≥ 275 MPa
Tensile Strength	≥ 345 MPa
Elongation	≥ 20%
Density	4.51 g/cm³
Thermal Conductivity	21.9 W/m·K
Melting Point	1668°C

Ultra Thin Titanium Foil Customization & Services

Slitting & Cutting: Precision coil slitting and laser cutting to exact dimensions
Surface Treatment: Acid cleaning, passivation, or customized finishing options
Packaging Options: Cleanroom bagging, spool winding, or flat stacking
Rapid Prototyping: Small batch production for R&D and new product trials

How to Bulk Order Ultra Thin Titanium Foil

To receive a quote or request a sample, please contact our sales team with the following details:

Desired grade and thickness
Width and length/roll requirements
Surface finish preference
Application and tolerance needs

With expertise in titanium processing, BYC Ti is a trusted supplier of precision titanium materials to clients across aerospace, medical, and industrial sectors. Our ultra-thin titanium foils reflect our commitment to quality, innovation, and technical excellence.
