Key Properties
Superior Corrosion Resistance: GR2 Titanium Plate forms a self-healing oxide layer that provides outstanding protection against seawater, acids, and chloride environments. Its resistance to pitting and crevice corrosion surpasses many conventional metals, ensuring long-term durability in harsh conditions.
Balanced Strength & Ductility: With higher tensile and yield strengths compared to GR1, GR2 combines robust structural integrity with excellent formability. It can withstand greater stress while remaining malleable enough for complex shaping, ideal for parts requiring both strength and precision.
Low Density: Weighing significantly less than steel or aluminum alloys, GR2 titanium reduces component weight without sacrificing performance, optimizing efficiency in transportation and aerospace applications.
Biocompatibility & Hygiene: Safe for direct contact with biological tissues, GR2 is frequently used in medical implants and food processing equipment, meeting stringent biocompatibility standards.
Chemical Composition
Element | Content (%) |
Titanium (Ti) | Balance |
Iron (Fe) | ≤0.30 |
Oxygen (O) | ≤0.25 |
Nitrogen (N) | ≤0.03 |
Hydrogen (H) | ≤0.015 |
Other elements | Trace amounts |
Mechanical Properties
Tensile Strength: 345 - 450 MPa
Yield Strength: 275 - 380 MPa
Elongation: ≥20%
Hardness (Rockwell B): 60 - 80
Dimensions & Tolerances
Thickness: Available from 0.3mm to 150mm, with precise thickness control ensuring uniform quality.
Width: Standard widths range from 600mm to 3000mm; custom widths can be tailored to project needs.
Length: Flexible lengths up to 6000mm or customized per order, minimizing material waste.
Surface Finish Options
Mill Finish: The default surface from the rolling process, offering a smooth, matte texture.
Polished Finish: A mirror-like surface treatment that enhances aesthetics and corrosion resistance.
Pickled & Brushed Finish: Removes surface oxides and provides a uniform, scratch-resistant texture.
Applications
Aerospace: Used in aircraft frames, engine components, and landing gear due to its high strength-to-weight ratio and resistance to fatigue.
Marine Engineering: Ideal for ship hulls, propellers, and offshore structures, enduring constant exposure to saltwater and harsh weather.
Medical Devices: Preferred for orthopedic implants, surgical instruments, and dental fixtures, thanks to its biocompatibility and corrosion resistance.
Industrial Equipment: Applied in chemical reactors, heat exchangers, and pumps, where resistance to aggressive chemicals is critical.
Automotive: Utilized in high-performance parts like exhaust systems and suspension components, reducing weight and improving fuel efficiency.
Quality Assurance
Our GR2 Titanium Plates undergo rigorous quality control at every stage, from raw material inspection to final product testing. Each plate is certified through:
Chemical analysis to verify alloy composition
Mechanical testing for tensile, yield, and elongation properties
Non-destructive testing (NDT) including ultrasonic and radiographic inspection
Visual inspection for surface integrity
All products comply with international standards such as ASTM B265, ASME SB-265, and ISO 5832-2.
Customization Services
We offer comprehensive customization options:
Tailored dimensions and shapes to fit specific project requirements
Custom surface treatments for enhanced functionality or appearance
Heat treatment services to optimize mechanical properties
Precision cutting and edge machining for ready-to-use components
Ordering & Delivery
Place your order by contacting our sales team with your specifications. We provide:
Competitive pricing based on order volume
Fast turnaround times for both standard and custom orders
Secure packaging and global shipping options to ensure timely, damage-free delivery
Elevate your projects with the reliability and performance of GR2 Titanium Plates. Contact us today to discuss your needs and receive a personalized solution.
