Advantages
Aerospace-Grade Strength – Tensile strength up to 1,000 MPa, outperforming steel while being significantly lighter.
Corrosion-Resistant – Immune to seawater, chlorine, acids (HCl, H₂SO₄), and industrial chemicals.
Biocompatible – ASTM F136 compliant, making it ideal for surgical implants and medical devices.
High-Temperature Stability – Maintains integrity from -100°C to 550°C, suitable for heat exchangers and aerospace components.
Non-Magnetic & Low Thermal Expansion – Perfect for MRI machines and precision instruments.
Applications
Aerospace & Defense – Aircraft hydraulic lines, fuel systems, structural components (high strength-to-weight ratio).
Chemical Processing – Reactor coils, acid transport, heat exchangers (resists HCl, H₂SO₄).
Medical & Dental – Surgical implants, prosthetics, MRI-compatible devices (biocompatible, non-magnetic).
Marine & Offshore – Desalination plants, seawater cooling systems (no pitting/crevice corrosion).
Automotive & Motorsports – High-performance exhaust systems, racing components (heat-resistant, lightweight).
Manufacturing Process
Vacuum Arc Remelting (VAR) – Ensures high-purity titanium ingots (Fe <0.25%, O <0.20%).
Hot Extrusion & Cold Drawing – Achieves precise dimensions (±0.05mm) and uniform grain structure.
Seamless vs. Welded Options:
Seamless: Hot piercing + cold drawing for high-pressure applications.
Welded: TIG-welded sheets for large diameters (OD >114mm).
Heat Treatment – Stress-relief annealing (750°C) to prevent cracking.
Surface Finishing – Pickling (HNO₃/HF) or electropolishing for corrosion resistance.
GR5 Technical Specifications
Category | Parameter | Value / Range | Unit / Notes |
Mechanical Properties | Tensile Strength | ≥ 895 (annealed) / ≥ 930 (solution treated) | MPa |
| Yield Strength | ≥ 828 (annealed) / ≥ 860 (solution treated) | MPa |
| Elongation at Break | ≥ 10 – 14 | % |
| Hardness | 36 – 41 | HRC / varies by treatment |
| Fatigue Strength (unnotched) | ~510 | MPa |
Physical Properties | Density | 4.43 | g/cm³ |
| Melting Point | 1,660 | °C |
| Thermal Conductivity | 6.7 | W/m·K |
| Specific Heat Capacity | 560 | J/kg·K |
| Electrical Resistivity | ~1.6 | µΩ·m |
| Modulus of Elasticity | 110 | GPa |
| Poisson's Ratio | 0.32 | — |
Why Partner With Us?
Full Material Traceability – Mill test reports for every batch.
Custom Sizes & Finishes – Laser-cut, bent, or flanged ends.
Fast Lead Times – Standard sizes ship in 5–7 days.
Request a Quote Today! – Bulk discounts for OEMs & wholesalers.
