Key Properties
Corrosion Resistance: GR1 Titanium Plate exhibits outstanding resistance to corrosion, even in harsh environments. It forms a thin, adherent oxide film on its surface, which acts as a protective barrier against various corrosive media, including seawater, chlorides, and many acids. This makes it a top pick for marine, chemical processing, and desalination applications.
Low Density: With a density significantly lower than traditional metals like steel, GR1 titanium plate allows for the creation of lightweight components without sacrificing strength. This characteristic is highly valued in the aerospace and automotive industries, where reducing weight can enhance fuel efficiency and performance.
Good Formability: The material can be easily cold-worked, hot-worked, and formed into various shapes and sizes, providing flexibility in manufacturing processes. It can be rolled, stamped, and welded, enabling the production of complex parts with precision.
Biocompatibility: GR1 titanium is biocompatible, meaning it can safely interact with the human body without causing adverse reactions. This property makes it suitable for medical implants, such as dental fixtures and orthopedic plates.
Chemical Composition
Element | Content (%) |
Titanium (Ti) | Balance |
Iron (Fe) | ≤0.20 |
Oxygen (O) | ≤0.18 |
Nitrogen (N) | ≤0.03 |
Hydrogen (H) | ≤0.015 |
Other elements | Trace amounts |
Mechanical Properties
Tensile Strength: 240 - 345 MPa
Yield Strength: 170 - 275 MPa
Elongation: ≥24%
Hardness (Rockwell B): 55 - 70
Dimensions and Tolerances
Thickness: Available from 0.5mm to 100mm, with tight thickness tolerances to ensure consistent quality.
Width: Standard widths range from 500mm to 3000mm, but custom widths can be provided upon request.
Length: Custom lengths are available to meet your specific project requirements, ensuring minimal material waste.
Surface Finish
Our GR1 Titanium Plates are available with a variety of surface finishes:
Mill Finish: The standard finish obtained directly from the rolling process, providing a smooth, matte surface.
Bright Annealed Finish: A highly polished surface finish that offers enhanced aesthetics and improved corrosion resistance.
Pickled Finish: Removes the oxide layer formed during heat treatment, resulting in a clean, bright surface.
Applications
Aerospace: Used in aircraft structures, engine components, and interior parts, where its lightweight and high-strength properties contribute to improved fuel efficiency and performance.
Medical: Ideal for medical implants, surgical instruments, and prosthetics, thanks to its biocompatibility and corrosion resistance.
Marine: Suitable for shipbuilding, offshore platforms, and marine equipment, as it can withstand the corrosive effects of seawater.
Chemical Processing: Used in chemical reactors, heat exchangers, and pipelines, due to its excellent resistance to chemical corrosion.
Automotive: Applied in automotive components, such as exhaust systems and suspension parts, to reduce weight and improve fuel economy.
Quality Assurance
At BYC Ti, we are committed to delivering the highest quality GR1 Titanium Plates. Each plate undergoes rigorous quality control processes, including chemical analysis, mechanical testing, and non-destructive testing (NDT) methods such as ultrasonic testing and eddy current testing. Our products comply with international standards, including ASTM B265, ASME SB-265, and ISO 5832-2, ensuring consistent quality and reliability.
Customization Options
We understand that every project is unique, which is why we offer a wide range of customization options for our GR1 Titanium Plates. Whether you need a specific size, shape, surface finish, or mechanical property, our team of experts is ready to work with you to develop a solution that meets your exact requirements.
Ordering and Delivery
Ordering our GR1 Titanium Plates is easy. Simply contact our sales team with your specifications, and we will provide you with a competitive quote. We offer fast and reliable delivery options, ensuring that your order arrives on time and in perfect condition.
Experience the superior quality and performance of our GR1 Titanium Plates. Contact us today to discuss your project requirements and find the perfect solution for your application.
